Description

Main Parameters

Nominal Pressure: 4.0MPa

Nominal Diameter: DN15-DN40

Applicable Media: Gases or liquids such as NG, O2, N2, Ar, etc.

Applicable Temperature: -196°C ~ +85°C

Connection Type: Welded, Threaded Connection

Media Flow Direction: From bottom to top of valve disc

Testing and Inspection: GB/T 12237

Main Component Materials

Valve Body: ASTM A351 CF8

Ball: ASTM A182 F304

Ball Liner: PTFE

Valve Body Gasket: PTFE
