Description

Main Parameters

Nominal Pressure: 4.0 MPa

Nominal Diameter: 10～25 mm

Valve Body, Cover, Spring: Stainless Steel

Seal Material: Hard Alloy

Applicable Media: Gases or liquids such as NG, O2, N2, Ar

Applicable Temperature: -196°C ~ +80°C

Connection Type: Threaded

Media Flow Direction: From bottom to top of valve disc

Testing and Inspection: GB/T12241, GB/T12242, GB/T12243
