Description
Technical Parameters
| Name | Anchor Chain Diameter (mm) | Working Load (kN) | Anchoring Speed (m/min) | System Load (kN) | Mooring Speed (m/min) | Wire Rope Diameter (Mm) | Motor Power (kw) |
| ø12.5/14 Electric Anchor Windlass | 12.5/14 | 5.9/7.4 | ≥12 | 5 | ≥10 | 11 | 4.3/1.7 |
| ø12.5/14/16/17.5 Electric Anchor Windlass | 12.5/14/16/17.5 | 5.9/7.4/10.9/13.0 | ≥12 | 8 | ≥10 | 13 | 8.5/3.5 |
| ø19/22 Electric Anchor Windlass | 19/22 | 15.3/20.6 | ≥12 | 10 | ≥10 | 13 | 8.5/3.5 |
| ø26 Electric Anchor Windlass | 26 | 28.7 | ≥9 | 20 | ≥8.5 | 15 | 11/11/7.5 |
| ø28 Electric Anchor Windlass | 28 | 33.3 | ≥9 | 30 | ≥8.5 | 17.5 | 16/16/11 |
| ø30/32 Electric Anchor Windlass | 30/32 | 38.3/43.5 | ≥9 | 30 | ≥8.5 | 17.5 | 16/16/11 |
| ø34/36 Electric Anchor Windlass | 34/36 | 49.1/55.1 | ≥9 | 30 | ≥8.5 | 17.5 | 22/22/16 |
| ø38/40 Electric Anchor Windlass | 38/40 | 61.4/68.0 | ≥9 | 50 | ≥8.5 | 20.5 | 22/22/16 |
